General Features
Working Temperature
-15 C / +180 C
Interchange
ISO 7241 -1 A
Operating Pressure
Up to 190 Bar
Available Threads
BSP - NPT
Available Sizes
From 1/4" 2"
Sealing Description
Viton
Locking Mechanism
Locking Ball System
Flow Rate
Up to753 / min
Material
Brass
Main Applications
Agriculture
Chemical Industry
Concrete Vehicles
Earth Moving
Hydraulic Industry
Hydraulic Equipment
Oil & Gas
Vehicles
