QC-S Series Stainless Steel

General Features
Working Temperature -15 C / +180 C
Interchange ISO 7241 -1 A
Operating Pressure Up to 350 Bar
Available Threads BSP - NPT
Available Sizes From 3/8" to 1"
Sealing Description Viton
Locking Mechanism Locking Ball System
Flow Rate Up to 258 l / min
Material AISI 316-L Stainless Steel
Main Applications
Chemical Industry
Concrete Vehicles
Earth Moving
Hydraulic Industry
Hydraulic Equipment
Oil & Gas
